Diesel Powered Articulated Boom Lift 14,2 m
Product group code: 2692925
MANITOU 160ATJ+
The high capacity 160 ATJ+ MEWP is designed to safely accommodate a maximum of 3 operators. Equipped with a hinged structure, it allows you to work at height (16.25 meters maximum) with precision and speed. With its all-terrain design, the diesel 160 ATJ + is ideal to operate outside, including on uneven, irregular and muddy conditions. Intuitive controls and many safety systems make it an indispensable lift for all your handling and maintenance in the field of construction (structure / light work), cleaning, sandblasting, trimming or event.
Accessories for rent
Fall Protection Clamp 2 m
Body Harness P-30mX
Body Harness
Harness Miller Titan 2-point
Platform height | 14,2 m |
Horizontal outreach | 8,94 m |
Weight | 8100 kg |
Max load weight | 400 kg |
Platform dimensions | 2,3x0,93 m |
Ground clearance | 425 mm |
Working height | 16,2 m |
Up and over height | 7 m |
Drive or power source | Diesel |
Jib length | 1,5 m |
Wheel drive / steering | 4WD/4WS |
Tyres | Foam filled |
Fuel tank capacity | 52 l |
Platform length | 2,3 m |
Platform width | 0,93 m |
Transport length | 4,82 m |
Transport width | 2,3 m |
Transport height | 2,7 m |
Length | 6,92 m |
Width | 2,3 m |
Height | 2,37 m |
Safety harnesses are always recommended when there is a risk of falling from the platform. The use of safety harnesses is mandatory in telescopic and articulated boom lifts.
We recommend that the user wears protective shoes to reduce risks of injury.
